| GESBC-9260S no serial response |
|
|
|
embedded.user writes "I recently bought an embedded linux board from glomation, specifically the GESBC-9260S.
The serial port is silent, i dont get a response when using minicom (hyperterminal), it is not my computer's problem as i have no problem talking to MikroTik RouterBOARDS.
I have set the bits per second to 115200, 8 data bits, no parity.
Am i missing something? I have read the manual thoroughly and does not give any advice in this situation.
Is there anyway to communicate with the board through some other port? such as ethernet port?"
|
|
|
|
| uClinux on stm32f103 problem |
|
|
|
|
neo17_04 writes "Hi everybody,
I need an help on using uClinux on stm32f103. The problem is I need to develop an application which makes to communicate microcontroller and PC via USB. So I made an application that I want to run from uClinux shell. To configure usb protocol, I need to change priority group and access to SCB -> AIRCR register (0xE000 0000 of Cortex-M3 internal peripherals memory). Moreover NVIC register are also located into Cortex-M3 internal peripherals memory. The problem is that when I launch my application from shell, I got a segmentation fault when the operating system runs the part related to "USB_interrupt_configuration". I think I don't have appropriate privilege to access to those registers. In fact when I run the function "__get_control()" included in "core_cm3.c" file, I got the value "0x0000003". Am I wrong? So what can I do to have complete access to stm32f103 registers when i develop an application that I want to run under uClinux operating system? Thanks in advance to all people who will help me to solve the problem.
Best regards
Neo."
|
|
|
|
| MINI2440 with LCD Samsung S3C2440 development kit |
|
|
|
| xcopilot + uclinux make fail |
|
|
|
n1md4 writes "I'm trying to build a linux controlled robot, and uClinux is how I'd like to start.
I've been following the tutorial at http://www.ucdot.org/archive/tb/tb20020807.shtml but have failed at making xcopilot:-
gcc -DHAVE_CONFIG_H -I. -I. -I.. -I.. -g -O2 -c custom.c
custom.c:803: error: static declaration of ‘cycles’ follows non-static declaration
custom.h:46: note: previous declaration of ‘cycles’ was here
custom.c: In function ‘custom_wput’:
custom.c:1593: warning: ignoring return value of ‘write’, declared with attribute warn_unused_result
custom.c: In function ‘custom_bput’:
custom.c:1898: warning: incompatible implicit declaration of built-in function ‘abort’
custom.c:1917: warning: ignoring return value of ‘write’, declared with attribute warn_unused_result
make[2]: *** [custom.o] Error 1
make[2]: Leaving directory `/home/nimda/xcopilot/mc68k'
make[1]: *** [all-recursive] Error 1
make[1]: Leaving directory `/home/nimda/xcopilot'
make: *** [all-recursive-am] Error 2
There is a note, on the website, "Providing all the correct libraries are in place, the result will be an Xcopilot that is ready to use." I'm not sure what the "correct" libraries are?
I'd be really grateful for any assistance.
Thanks,
Jon"
|
|
|
|
| Converting a Hardware GUI to a Web Interface |
|
|
|
|
John Vickers writes "Hey everyone!
I am looking for a solution to a problem. I have some hardware we are developing at work that currently uses RS232 to interface with a control GUI I have written. We have just recently started demoing the hardware to prospective buyers and I am being told over and over that the control interface needs to be a web interface. (The hardware is a Free Space Optical Link - Gigabit over the air)
I figure the easiest way to provide this functionality without a board redesign is to use an embedded computer with an RS232 port, web server, and RJ45 port to host a Web Interface that can talk over the RS232 port to our board beside it.
I want to do this for as cheap as possible, so it seems like it would be better to go with linux than windows, but I don't even know where to start on this project.
Can anyone suggest anything?
Thanks!"
|
|
|
|
| S5PC100 Evaluation Board and Driver |
|
|
|
Ritu Raj writes "S5PC100 is a 32-bit RISC low power, high performance micro-processor and adopts a 64-bit internal bus architecture and includes many powerful hardware accelerators for mobile phones and general applications, S5PC100's Multi Format CODEC provides encoding and decoding of MPEG-4/H.263/H.264up to 30fps@HD(720p) and decoding of MPEG-2/VC1/Divx/Xvid video up to 30fps@HD(720p).For detail information regarding S5PC100 Evaluation Board, Pls. visit the site http://www.prosoftworld.net/s5pc100_evaluationboar d.html"
|
|
|
|
| Cortex-A8 S5PC100 Development Board |
|
|
|
|
Shan You writes "Kit-Kit-S5PC100 Description
KIT-S5PC100 Evaluation Board is a compact board using S5PC100 microprocessor. It takes full features of this processor and supports 512MB DDR2 memory. The board has exposed many other hardware interfaces including RS232 serial port, LCD/TSP, HDMI, SD/MMC, TF-card interface, keyboard, WiFi, The board boot the system from SD card. It is able to support Android OS and provided the sourece code for the Linux-2.6.29 BSP and Android 1.5-R3.
KIT-S5PC100 Evaluation Kit includes the KIT-S5PC100 evaluation board and all necessary accessories to help users start their design of multimedia applications. The board is preloaded with Android OS in SD card. User can display the subsystem using a 3.5" TFT LCD and Touch screen. Along with the kit, Boardcon provides user manual, schematic drawing and datasheet documents to help customers better understand and use the kit.
For more information about the development Kit, please check on website: http://www.armdesigner.com/KIT%20S5PC100.html"
S5PC100 Highlights:
|
|
|
|
| ATMEL SAM9G45 ARM9 Development Board |
|
|
|
daniel_Je writes "
The SAM9G45 ARM9 Board is a new released compact board by Embest in 2010, based on the ATMEL AT91SAM9G45 processor, works at up to 400MHz and provides plenty of internal memory and external memory. The board features a wide range of peripherals, including UART, USB host, USB device, Ethernet, SD/MMC, Micro SD, TFT LCD, User extension interfaces, key buttons and IIS Audio Input/Output Jack. In addition, the board supports Linux2.6 and WinCE6.0 OS and offers plenty of example programs which makes your design and development much more easier.
- Supports Linux2.6, WinCE6.0 OS
- On-chip memory: 64KB ROM & 64KB SRAM
- External memory: 256MBNandFlash, 2MB NorFlash, 4MB DataFlash & two 64MB DDR2 SDRAM
- Features a 4.3" QVGA 320x240 LCD panel with Resistive touch screen
More info: http://www.embedinfo.com/en/list.asp?id=72.
"
|
|
|
|
|
|
